        ESTIMATE  FOR MANUFACTURING OF FERRIC & NON-FERRICALUM

                                                   CAPACITY-5 MT EACH PER DAY

LIST OF PLANT & MACHINERY                                         QTY             Rate           Amount

1.      SULFURIC  ACID STORAGE TANK M.S. 10mm                                             5nos                7,50,000              37,50,000

THICKCAPACITY 1O MT SIZE 6.5Dia x12.5 long

With pumps.2”x2” line, manhole with cover inlet,

Outlet,stand, valves all complete.

      2.Alum crusher Pulverizer 7.5 HPmotor,  speed reducer

        Crusher capacity 1 MT per hour, all attached                                                       1no             15,00,000            15,00,000

   3.Bucket Elevator 2 HP complete accessorieswith buckets

     Up to height  of 15 ft from ground up to the reactor.                                             1no               8,50,000                8,50,000

  4.Steam Boiler 2 MT /Hour steam heated withcompact thermic                       2 no             25,00,000           50,00,000

Fluid,Diesel gas fired with complete accessories, Pipelines 2”dia,

Valves, Gaugesof Pressures, Valves, Safety Valves, insulation,

Watersoftner etc.

5.M.S. leadlined Reactors, Capacity 5 MT size 5.5’X8’ height.                2nos              15,00,000                        30,00,000

Homogenized leadlining 5 mm on M.S. 6mm, 10 HP motor,

Spreadreduces complete top manhole with cover, bottom set

With onedischarge gate valve 4”x2” lines from Sulfuric Acid

Liftingpump.

6.Vacuum  Evaporator capacity 10 MT with  all arrangements, 5mm     2nos         25,00,000                        50,00,000

M.S. withhomogenized 5mm lead lined, Pipe line with mist type water

Jet vacuumcondenser; evaporator size 6.5ft dia X 12.5 height , top entry

Line 4” fromreactor

7. PollutionControl for Acid fumer, placed on top of the reactor fitted    2nos       12,50,000                       25,00,000

With Coldwater sprinklers and recycled to reactor.

8. TestingLab equipments.                                                                                            Lot         5,00,000                         5,00,000

9. Weighbridge 10 MT electronic and computerized.                                         Lot      20,00,000                      20,00,000

10. Staging,supports, ladder, railing , nut bolts etc.                                            Lot        50,00,000                       50,00,000

11. Pipes,valves, pumps, motors.                                                                               Lot       30,00,000                        30,00,000

13.Maintatenceworkshop, viz lathe, dril,  cutting,wielding, tools etc.                                                                 15,00,000

14.conveyers,horizontal with 2 HP motors, gears, controls etc.                    5           3,50,000                         17,50,000

15. AmoniumAlum, , Potash Alum System, Sodium Alum                                                                                          30,00,000

16. SS Tray200X 50 kg .  (600 Pcs)                                                                                                                                         3,00,000

17.Dryer                                                                                                          3                                                                             30,00,000

18. MaterialHandling System                                                                                                                                                 10,00,000

TOTAL                                                                                                                                                                                          Rs4,26,50,000

ForM.I.Equipments Pvt Ltd

IndrajitBanerjee

Director
